SA192 Bahan tabung penjimat penukar panas untuk pabrik gula
Product Details
| Dimensi Tabung: | OD32mm * Ketebalan 4mm | Efisiensi Termal: | Lebih dari 80% |
|---|---|---|---|
| Fungsi: | Pertukaran panas | Efisiensi: | ≥ 90% |
| Dimensi: | 168mmx7.11mmx18000 | Pelabuhan: | Shanghai |
| Standar: | SEPERTI SAYA | Penggunaan: | Pembangkit Listrik/CFB Boiler |
| Tekanan Kerja: | 0,5MPa~2,45Mpa | Bahan: | Baja karbon |
| Model: | Bagian Ketel | Jaminan: | 1 tahun |
| Spesifikasi: | Disesuaikan | Pelabuhan pemuatan: | Shanghai |
| Rentang Aplikasi: | Industri/Pembangkit Listrik | ||
| Menyoroti |
Bahan tabung penghemat SA192,Bahan tabung penghemat gula pabrik gula,bahan penukar panas penghemat |
||
Product Description
SA192 Base Tube Made Boiler Economizers untuk pabrik gula
Rincian produk
Boiler economizer adalah permukaan pemanasan belakang boiler, yang biasanya terletak di outlet boiler.Economizer mengumpulkan panas dari flue dan meningkatkan suhu masuk boiler melalui panas limbah dari gas flueSementara menurunkan suhu knalpot, meningkatkan suhu masuk boiler, mengurangi tekanan termal yang disebabkan oleh perbedaan suhu antara dinding drum dan air masuk,dan mengurangi penyusutan dan ekspansi drum. Economizer perusahaan kami umumnya mengadopsi 20 tabung boiler tekanan menengah dan rendah, tabung baja 20g tanpa jahitan atau tabung baja kelas ASME.memulihkan panas sejauh mungkin, dan meningkatkan efisiensi keseluruhan boiler, sehingga membantu pelanggan mengurangi konsumsi bahan bakar dan mengurangi biaya boiler.
Fungsi dari Boiler Economizer
Kita dapat meringkas fungsi ekonomizer sebagai berikut:
1. penghematan bahan bakar: penghematan diletakkan di bagian belakang boiler. Dengan cara ini dapat menurunkan suhu asap dan gas, sehingga menghemat bahan bakar.
2.meningkatkan kondisi kerja drum uap: karena ekonomizer, suhu air masuk meningkat saat memasuki drum uap.Ini mengurangi perbedaan suhu antara air masuk dan dinding drum uap serta tekanan termal drum uap, sehingga meningkatkan kondisi kerja drum uap dan memperpanjang umur layanan.
3.mengurangi biaya pembuatan boiler: karena air input dipanaskan di boiler economizers.Penggunaan suku cadang suhu rendah sebagai penghematan boiler untuk menggantikan beberapa panel dinding air suhu tinggi yang mahal mengurangi biaya untuk memproduksi boiler.
Spesifikasi
| Deskripsi | Penjimat boiler |
| Bahan | Baja paduan, baja karbon, SA210C,SA213T22, dll. |
| Standar bahan | ASTM, EN atau ISO dll. |
| Dimensi | Pengaturan khusus |
| Berat badan | Min: 10 ton Maks.:1000 ton |
| Proses peleburan: | EF+LF + VD |
| Proses | Material→Ingot → Hot/Cold-Rolling→ Pengolahan panas (Normalizing+ tempering) → Inspeksi →Pengolahan kasar→UT →Pengolahan panas kedua →Pengolahan akhir →Pengolahan |
| Standar UT | ASTM A388 atau EN10228, dll. |
